CHAPTER 2 BASIC OPERATION
COPYRIGHT © 1999 CANON INC. CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
2-3
C. Basic Sequence of Operations
• A4R, Direct, 2 Copies, Continuous, Cassette
I : Scanner home position detection
II : Lens home position detection
Figure 2-103
Copy Start keyPower switch
ONON
STBY INTR AER
SCFW
Forward
SCFW
SCRV
LSTR
STBY
Main motor (M1)
Scanning lamp (LA1)
Primary AC bias
Transfer bias
Static eliminator bias
Fixing heater (H1)
Primary DC bias
Developing AC bias
0.3sec (approx.)
Developing DC bias
Scanner
SCRV
Reverse
III I
To Next Page
