CHAPTER 7 EXTERNALS/AUXILIARY MECHANISMS
COPYRIGHT
©
1999 CANON INC. CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
7-1
Figure 7-101
Heat exhausting fan
FM1
I. FANS
The machine is equipped with two fans serving to discharge ozone or cool its inside.
The heat exhaust fan is driven directly by the main motor (M1; through a belt and a gear), and
is designed to rotate at all times while the main motor is rotating.
