CHAPTER 1 GENERAL DESCRIPTION
COPYRIGHT © 1999 CANON INC. CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON) 1-20
Scanning lamp
Copyboard glass
Fixed focal point lens
Side blanking lamp
(front, rear)
Developing blade
Developing cylinder
Primary charging roller
Cleaning blade
Transfer charging roller
Static eliminator
Fixing assembly
Photosensitive drum
VI. IMAGE FORMATION
A. Outline
The construction of the machine is as follows:
Figure 1-601
