CHAPTER 3 EXPOSURE SYSTEM
COPYRIGHT
©
1999 CANON INC. CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
3-38
Figure 3-349
[7]
[6]
5) While pushing the electrode mount [6]
found at the rear of the machine in the di-
rection of the arrow, detach the scanning
lamp [7].
Caution:
1. Do not start the work if the scanning
lamp is hot.
2. Do not leave fingerprints on the sur-
face of the scanning lamp.
3. If the surface of the scanning lamp is
soiled, dry wipe it.
To Next Page
