Follow the instructions on the screen to remove the paper, and redo the operation.
2. Open top cover and lift release lever.
Important
• Do not touch the linear scale (A), carriage shaft (B), or ink tube stabilizer (C). Touching these may
cause malfunction.
3. Place cut sheet with the print side up, insert in portrait orientation between platen (A) and
paper retainer (B), and align paper's far edge using the following steps.
103
To Next Page
