Specifications
Important
• The following values may vary depending on the operating environment.
Printer
Power supply 100-240 V AC (50/60 Hz)
Power consumption When printing: 105 W max.
In Sleep mode: 3.6 W max. *1
When power is off: 0.3 W max. *1 *2
*1 Wired LAN connection
*2 The printer uses a trace amount of power even when turned off. To stop all
power consumption, turn off the printer and unplug the power cord.
Operating environment Temperature: 59 to 86 °F (15 to 30 °C)
Humidity: 10 to 80 % RH (with no condensation)
Dimensions (W x D x H) Main unit only:
Approx. 54.8 x 28.9 x 24.8 inches (1390 x 734 x 628 mm)
Main unit and Stand (when basket is not used):
Approx. 54.8 x 30.2 x 46 inches (1390 x 766 x 1168 mm)
Main unit and Stand (when using basket: Basket Position 1) *1:
Approx. 54.8 x 38.8 x 46 inches (1390 x 984 x 1168 mm)
Main unit and Stand (when using basket: Basket Position 2/4/5) *1:
Approx. 54.8 x 48.2 x 46 inches (1390 x 1222 x 1168 mm)
Main unit and Stand (when using basket: Basket Position 3) *1:
Approx. 54.8 x 56.5 x 46 inches (1390 x 1434 x 1168 mm)
Main unit and Stacker (with Stacker Position Closed) *2:
Approx. 54.8 x 44.2 x 46 inches (1390 x 1122 x 1168 mm)
Main unit and Stacker (with Stacker Position Open) *2:
Approx. 54.8 x 46.8 x 46 inches (1390 x 1188 x 1168 mm)
*1 For details on the Basket Position, see Example Basket Configurations.
*2 For details on the Stacker Position, see Example Stacker Configurations.
Weight Main unit only (does not include print head and ink tanks):
Approx. 191 lb (87 kg)
Stand and Basket: Approx. 40 lb (18 kg)
Roll unit: Approx. 42 lb (19 kg)
Stacker: Approx. 31 lb (14 kg)
Space for installation (W x D x
H)
Main unit and Stand (when basket is not used):
Approx. 70.5 x 57.8 x 61.5 inches (1790 x 1466 x 1560 mm)
485
