Main unit and Stand (when basket is used):
Approx. 70.5 x 66.3 x 61.5 inches (1790 x 1684 x 1560 mm)
Main unit and Stacker:
Approx. 70.5 x 74.4 x 61.5 inches (1790 x 1888 x 1560 mm)
Printing performance
Print method Bubblejet
Maximum resolution 2400 dpi (horizontally) * x 1200 dpi (vertically)
* Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Print head PF-06
Number of nozzles MBK: 5120 nozzles, others: each 2560 nozzles
Memory and hard disk
Memory 128 GB (2GB physical memory)
Hard disk capacity 500 GB (encryption)
Personal mail boxes (Permanent storage area): 180 GB
Print job storage capacity Common Box: 100 jobs
Personal Boxes: 100 jobs
Interface
You can use both USB and LAN at the same time.
You cannot use wireless LAN and wired LAN at the same time.
USB Hi-Speed USB *
* To use Hi-Speed USB, your computer must support Hi-Speed USB. Addition-
ally, the Hi-Speed USB interface is completely backward compatible with USB
1.1, so the printer can be connected even if the computer interface is USB 1.1.
USB memory USB flash drive
LAN Wired LAN: IEEE802.3ab (1000BASE-T) / IEEE802.3u (100BASE-TX) /
IEEE802.3 (10BASE-T)
Wireless LAN: IEEE802.11n / IEEE802.11g / IEEE802.11b *
* A connection can be established by configuring Standard setup, WPS (Wi-Fi
Protected Setup), WCN (Windows Connect Now), Easy wireless connect.
Network Specifications
Communication protocol SNMP (Canon-MIB compatible), HTTP, TCP/IP (IPv4/IPv6), FTP
486
