Wired LAN Connection

Connect the printer and computer to a router using a LAN cable.

Note

• USB connection with a computer is available even while the printer is connected to a computer via

wired LAN.

For more on wired LAN connection:

What Is Ethernet Cable?

Restrictions

USB Connection

Connect the printer to a computer using a USB cable.

329
