23.7 fl oz (700 ml)

Colors Model number

Matte Black PFI-710 MBK

Black PFI-710 BK

Cyan PFI-710 C

Magenta PFI-710 M

Yellow PFI-710 Y

Note

• For instructions on replacing the ink tanks, see Replacing Ink Tanks.
