3. ELECTROMAGNETIC COMPABILITY (EMC)
3.2. Guidance and Manufacturer's declaration - Electromagnetic
immunity
The ECG100+/ECG200+/ECG100S/ECG200S is intended for use in the electromagnetic environment specified
below. The customer or the user of the ECG100+/ECG200+/ECG100S/ECG200S should assure that it is used
in such an environment.
Immunity test
Conformity
Compliance level
Electromagnetic Environmental Information
Electrostatic discharge
(ESD)
IEC 61000-4-2
+/- 6 kV contact
+/- 8 kV air
+/- 6 kV contact
+/- 8 kV air
Floors should be wood, concrete or ceramic tile. If
floors are covered with synthetic material, the
relative humidity should be at least 30 %.
Electrical Fast Transient/
Burst
IEC 61000-4-4
+/- 2 kV for power
supply lines
+/- 1 kV for
input/output lines
+/- 2 kV for power
supply lines
+/- 1 kV for
input/output lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5
+/- 1 kV line(s) to
line(s)
+/- 2 kV line(s) to
earth
+/- 1 kV line(s) to
line(s)
+/- 2 kV line(s) to
earth
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips,
short interruption and
voltage variations
on power supply
input
lines
IEC 61000-4-11
<5% U
T
(>95% dip in U
T
)
for 0.5 cycle
40% U
T
(60% dip in U
T
)
for 5 cycles
70% U
T
(60% dip in U
T
)
for 25 cycles
<5% U
T
(>95% dip in U
T
)
for 5 s
<5% U
T
(>95% dip in U
T
)
for 0.5 cycle
40% U
T
(60% dip in U
T
)
for 5 cycles
70% U
T
(60% dip in U
T
)
for 25 cycles
<5% U
T
(>95% dip in U
T
)
for 5 s
Mains power quality should be that of a typical
commercial or hospital environment. If the user of
the ECG100+ requires continued operation during
power mains interruptions, it is recommended that
ECG100+ be powered from an uninterruptible power
supply or a battery.
Power frequency and
magnetic field
(50/60 Hz)
3 A/m
3 A/m
Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.
NOTE: U
T
is the AC mains voltage prior to the application of the test level.
3.3. Guidance and Manufacturer's declaration - Electromagnetic
immunity
The ECG100+/ECG200+/ECG100S/ECG200S is intended for use in the electromagnetic environment specified
below. The customer or the user of the ECG100+/ECG200+/ECG100S/ECG200S should assure that it is used
in such an environment.
Emission test
IEC 60601 test level
Compliance level
Electromagnetic Environmental Information
Conducted RF
IEC 61000-4-6
3 V rms
From 150 kHz to 80
MHz
3 V
Portable and mobile RF communications equipment
should be used no closer to any part of the ECG100+,
including cables, than the recommended separation
