8. MENU AND DEVICE SETTINGS
Field
Description
Possible values
Display Race
Visibility of the race field in the patient's data and
in print.
Yes/No
Accession number
Visibility and editability of Accession Number field.
hidden/not editable/editable
Brightness
Brightness of the screen.
from 10% to 100%
Auto Turn off
Time of inactivity (without any key being pressed
and without any acquisition) after which the
device switches off automatically, if powered by
the battery.
15/ 30/60 minutes
Lead Type
Sets the name of displayed electrodes label
depending on the standard used.
If changed, it needs the device reboot to be
applied.
IEC/AHA
LF mask
Allows turning off the display of the square waves
in case of lead fail, so that you can see the real
signal. Useful for patients with high impedance or
with under-performing electrodes.
On/Off
External DICOM
(only
ECG100+/ECG200+)
This setting is displayed only if Connectivity
Option is DICOM and allows to choose if the
DICOM transmission has to be done using an
external gateway (Cardioline Gateway), If set to
Yes the external gateway is used.
Yes/No
Configuration PIN
Allows to set a 4 digits PIN in order to protect the
access to settings. If empty (default) the settings
are not protected.
Numeric (4 digits)
8.6.2. Default ECG settings (page 2)
Field
Description
Possible values
Interpretation
Automatic interpretation of the ECG (if the
electrocardiograph is provided with the
Interpretation option). If “off”, the interpretation
is not included in the ECG and in the print.
if “long”, the interpretation text is enriched with
additional explanatory statements.
Short/Long/Off
Leads order
Order in which tracings are displayed and printed.
Standard/Cabrera
Leads format
Initial tracings display format.
If changed, it needs the device reboot to be
applied.
12x1 (only
ECG200+/ECG200S)/ 6x2/6x1
1
st
/6x1 2
nd
/6x1 3
rd
/3x2 1
st
/3x2
2
nd
/3x1 1
st
/3x1 2
nd
/3x1 3
rd
/3x1
4
th
/ 3x1 5
th
Muscle filter
Initial value of filter for reducing the muscle noise.
It is only applied to the displayed tracings and not
on the saved data (SCP file).
If changed, it needs the device reboot to be
Off/25Hz/40Hz/150Hz
