Cardioline ECG100+ - Manual Printing Settings; Automatic Printing Settings

ECG100+ - ECG200+ - ECG100S - ECG200S
8. MENU AND DEVICE SETTINGS
Field
Description
Possible values
applied.
The 150 Hz filter is available only if using a
sampling frequency of 1000 Hz.
Speed
Initial speed of the tracings.
If changed, it needs the device reboot to be
applied.
50/25/10/ 5 mm/sec
Gain
Initial tracings amplitude.
If changed, it needs the device reboot to be
applied.
20/10/5 mm/mV
Autoprint
Automatic printing of examination at end of
acquisition.
On/Off
Autosave
Automatic saving of examination at end of
acquisition.
On/Off
QTcB
Activates the QT corrected calculation of Bazett
On/Off
QTcF
Activates the QT corrected calculation of
Fredericia
On/Off
8.6.3. Manual printing settings (page 3)
Field
Description
Possible values
3-Lead 1
st
1
st
lead in 3-channel print
From I to V6 (default II)
3-Lead 2
nd
2
nd
lead in 3-channel print
From I to V6 (default V1)
3-Lead 3
rd
3
rd
lead in 3-channel print
From I to V6 (default V5)
6-Lead 1
st
1
st
lead in 6-channel print
From I to V6 (default I)
6-Lead 2
nd
2
nd
lead in 6-channel print
From I to V6 (default II)
6-Lead 3
rd
3
rd
lead in 6-channel print
From I to V6 (default III)
6-Lead 4
th
4
th
lead in 6-channel print
From I to V6 (default VI)
6-Lead 5
th
5
th
lead in 6-channel print
From I to V6 (default V2)
6-Lead 6
th
6
th
lead in 6-channel print
From I to V6 (default V5)
8.6.4. Automatic printing settings (page 4)
Field
Description
Possible values
Printout format
Initial tracing printing format.
If changed, it needs the device reboot to be
applied.
12x1 (only
ECG200+/ECG200S)/6x2/3x4/
3x4+1/3x4+3
Department Header
Name of Department to insert in header
Alphanumerical (30
characters)
Rhythm Lead 1
1
st
rhythm lead (3x4+1 e 3x4+3)
From I to V6 (default II)
