Cardioline ECG100+ - TECHNICAL SPECIFICATIONS

ECG100+ - ECG200+ - ECG100S - ECG200S
13. TECHNICAL SPECIFICATION
13. TECHNICAL SPECIFICATIONS
ECG channels .....................................
12-lead (I, II, III, aVR-L-F, V1-6)
CMRR ................................................
> 100 dB
DC input impedance ..........................
No lead-off 100 MΩ
A/D converter ....................................
24 bit, 32 kHz
Sampling frequency ...........................
1000 Hz
A/D conversion ..................................
20 bit
Output data resolution ......................
< 1uV/LSB
Bandwidth .........................................
Performances equivalent to 0.05 – 300 Hz
Pacemaker detection .........................
Hardware detection coupled with convolution digital filtering
Filters ................................................
Linear phase digital diagnostic high-pass filter (according to 60601-2-
25 2nd ed.)
50/60 Hz AC interference adaptive digital filter
Digital low pass filters at 25/40/150 Hz, for display and printing only
Defibrillation protection ....................
AAMI/IEC standards
Front-end performance .....................
ANSI/AAMI IEC 60601-2-25:2011
Safety ................................................
EN 60601-1 internal power equipment - class I on external AC/DC
power supply
ANSI/AAMI ES1
CE1936
Conformance Standards ....................
Certified to AAMI Std. ES 60601-1, IEC Std.60601-2-25
Conforms to CSA Std. No.60601-1, No. 60601-2-25
ECG storage .......................................
Internal storage 100 ECGs, expansion 1000 ECGs (optional)
Display ...............................................
ECG100+/ECG100S: Backlit, colour LCD display, 4.3” ECG waveform
real-time tracing
ECG200+/ECG200S: Backlit, colour LCD display, 7” ECG waveform
real-time tracing
Thermal printer .................................
ECG100+/ECG100S: 8 dot/mm - 108mm; Z-fold 100x150mm
ECG200+/ECG200S: 8 dot/mm - 216mm; A4 Z-fold
Manual print ......................................
3, 6, 12 (only ECG200+/ECG200S) channels, 5/10/25/50 mm/s
Auto print ..........................................
Standard or Cabrera; 3, 3+1, 6, 12 (only ECG200+/ECG200S) channels
Patient Demographic, Global Measurements, Optional Interpretation
