3. ELECTROMAGNETIC COMPABILITY (EMC)
3.4. Recommended separation distances between portable and
mobile RF communications equipment and the
ECG100+/ECG200+/ECG100S/ECG200S
The ECG100+/ECG200+/ECG100S/ECG200S is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The customer or the user of the
ECG100+/ECG200+/ECG100S/ECG200S can help prevent electromagnetic interference by maintaining a
minimum distance between portable and mobile RF communications equipment (transmitters) and the
ECG100+/ECG200+/ECG100S/ECG200S as recommended below, according to the maximum output power of
the communications equipment.
Maximum rated power output of the
transmitter (W)
Separation distance according to frequency of transmitter (m)
150 KHz to 800 MHz
800 MHz to 2.5 GHz
800 MHz to 2.5 GHz
0.01
0.12
0.12
0.23
0.1
0.37
0.37
0.74
1
1.17
1.17
2.33
10
3.69
3.69
7.38
100
11.67
11.67
23.33
For transmitters rated at a maximum output power not listed above, the recommended separation distance
d in metres (m) can be estimated using the equation applicable to the frequency of the transmitter, where P
is the maximum output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
3.5. Transmission frequencies
Frequency
[MHz]
Channel
EIRP
Power
[mW]
EIRP
Measured
[dBm]
ERP =
EIRP/1.64
[Mw]
ERP =
EIRP/1.64
[dBm]
Standard
Modulation
2.412
1
8.43
9.26
5.14
5.64
802.11B
CCK, OFDM, BPSK, GPSK,
16-QAM, 64Q-AM
2.437
6
13.30
11.24
8.11
6.85
802.11B
CCK, OFDM, BPSK, GPSK,
16-QAM, 64Q-AM
2.480
13
11.67
10.67
7.12
6.50
802.11B
CCK, OFDM, BPSK, GPSK,
16-QAM, 64Q-AM
2.412
1
6.20
7.93
3.78
4.83
802.11G
CCK, OFDM, BPSK, GPSK,
