Cardioline ECG100+ - WLAN and WiFi Security Settings

ECG100+ - ECG200+ - ECG100S - ECG200S
8. MENU AND DEVICE SETTINGS
8.6.7. WLAN Settings (page 7)
Field
Description
Possible values
DHCP
DHCP on or off. With DHCP “On”, the network
automatically and dynamically assigns an IP
address to the device and therefore it is not
necessary to enter an IP address manually. With
DHCP “Off” the device's IP address, Gateway and
Sub Net Mask must be entered.
If changed, it needs the device reboot to be
applied.
On/Off
IP Address
Device IP address. Only editable if the DHCP is Off.
If changed, it needs the device reboot to be
applied.
XXX.XXX.XXX.XXX
Subnet Mask
Subnet mask (IPv4 format). Only editable if the
DHCP is Off.
If changed, it needs the device reboot to be
applied.
XXX.XXX.XXX.XXX
Gateway
Default gateway address (IPv4 format). Only
editable if the DHCP is Off.
If changed, it needs the device reboot to be
applied.
XXX.XXX.XXX.XXX
DNS
IP address of DNS
If changed, it needs the device reboot to be
applied.
XXX.XXX.XXX.XXX
8.6.8. WiFi security Settings (page 8)
Field
Description
Possible values
SSID (rescan)
Allows to select the available WiFi networks. It has
a dropdown list to select (via RIGHT button) the
enumerated networks.
The label will act as a button (pushed with Enter
or Space key) to trigger the network scan. During
the scan, a popup will show the operation is
ongoing.
Alphanumeric (64 characters)
Security
Allow to choose the security protocol for WiFi.
None / WEP / WPA/WPA2 /
WPA-EAP
Passphrase
To set the passphrase for WEP or WPA/WPA2
Visible only if security is WEP or WPA/WPA2.
Alphanumerical (24
characters)
Username
To set the username for WPA-EAP.
Visible only if security is WPA-EAP.
Alphanumerical (24
characters)
Password
To set the password for WPA-EAP.
Visible only if security is WEP or WPA/WPA2.
Alphanumerical (24
characters)
