Cardioline ECG100+ - Real-time ECG Display Data

ECG100+ - ECG200+ - ECG100S - ECG200S
5. INTRODUCTION
 Surname, Name: surname and name of the patient being examined, if entered.
 Heart Rate (HR): when a patient is connected to the device, his/her HR is viewed in real time.
 Speed: rate of the tracings in mm/s. Use the F1 key to modify speed to 5 mm/s, 10 mm/s, 25 mm/s
or 50 mm/s.
 Gain: amplitude of the waveform in mm/mV. Use the F2 key to modify the gain to 2.5 mm/mV5
mm/mV, 10 mm/mV, 20 mm/mV.
 Filter: step-by-step filter applied to the tracings. Use the F3 key to modify the filter applied between
off, 25 Hz, 40 Hz, 150 Hz.
 Battery charge: indicates the level the battery is charged.
 Time: indicates the time of the device
 WiFi connection: indicates the quality of the WiFi connection
 Messages: electrode failure indicator and other messages (if present).
 Memory: the number of tests that can still be saved in memory (archive size, 100 or 1000, minus the
number of tests already saved)
 Access mode: an open/closed padlock icon indicates the active access mode (anonymous or full
access), see par. 9.2.
