62-12259 2–14
2.5.4.8 Overload Ground Fault Module (OGF)
The OGF, see Figure 2.6, is located in the control box
(Figure 2.4). The module has two electrical safety fea-
tures which are active in both Engine and Electric Oper-
ation - Overload protection and Ground Fault (Leakage)
.In each case, the 00100 Overload / Ground Fault
alarm is activated and the unit shuts down. When ground
leakage is detected, the red LED on the OGF module will
be on continuously
Figure 2.6 OGF Module
LED
