62-61753-21
5-13
CONFIGURATION
SELECTIONS
DESCRIPTION
REMOTE SWITCH 1 (or 2)
This Configuration indicates to the
microprocessor that a remote switch
has not, or has, been installed and,
in installed, what type of switch it is.
The action taken by the micropro-
cessor will be in accordance with the
following "Shutdown" Configuration
setting.
SWITCH NOT
INSTALLED
DOOR OPEN
SWITCH OPEN
DOOR OPEN
SWITCH CLOSED
SWITCH ON CON-
TACTS OPEN
SWITCH ON CON-
TACTS CLOSED
Switch not installed = There is no remote 1 (or 2)
switch.
DOOR OPEN SWITCH OPEN = A Remote Door
Switch 1 (or 2) has been installed. The switch con-
tacts will be OPEN whenever the door is OPEN.
DOOR OPEN SWITCH CLOSED = A Remote Door
Switch 1 (or 2) has been installed. The switch con-
tacts will be CLOSED whenever the door is CLOSED.
SWITCH ON CONTACTS OPEN = A Remote Switch
1 (or 2) has been installed. The switch is to be con-
sidered "ON" when the contacts open.
SWITCH ON CONTACTS CLOSED = A Remote
Switch 1 (or 2) has been installed. The switch is to be
considered "ON" when the contacts close.
 REMOTE SWITCH 1 (or 2)
SHUTDOWN
This Configuration indicates to the
controller what action is to be taken if
the switch is activated
Remote Switch 1
(or 2) alarm will
not shutdown the
unit.
Remote Switch 1
(or 2) alarm will
shutdown the unit.
Data Recorder Only
Low Engine Speed
REMOTE SWITCH 1 (or 2) ALARM WILL NOT
SHUTDOWN THE UNIT = When the switch is acti-
vated an alarm will be generated but the unit will not
shutdown.
REMOTE SWITCH 1 (or 2) ALARM WILL SHUT-
DOWN THE UNIT = When the switch is activated an
alarm will be generated and the unit will be shutdown.
DATA RECORDER ONLY = When the switch is acti-
vated an alarm will not be generated but an event will
be recorded.
LOW ENGINE SPEED = When the switch is activated
the engine will operate in low speed.
  UNIT SHUTDOWN BELOW
(temperature)
OFF
120 to -20°F
(49 to -29°C)
If Door Switch= Unit Shutdown is selected:
OFF = the unit will shutdown at any ambient tempera-
ture.
Value = when ambient temperature is below the en-
tered value, shut down will be allowed. (When ambi-
ent temperature is above the entered value, the unit
will not shutdown.)
  RUN LOW SPEED BELOW
(temperature)
OFF
120 to -20°F
(49 to -29°C)
If Door Switch= Low Engine Speed is selected:
OFF = the unit will transition to low speed at any am-
bient temperature.
Value = when ambient temperature is below the en-
tered value, transition to low speed will be allowed.
(When ambient temperature is above the entered
value, the unit will not transition to low speed.)
SET TIME
Indicates to the controller the time and date for the Data Recorder Real
Time Clock.
 MONTH
1-12
Select the correct month of the year.
 DAY
1-31
Select the correct day of the month.
 YEAR
1998 - 2037
Select the correct year.
 HOURS
0-23
Select the correct hour (0-11 is AM / 12-23 is PM)
 MINUTES
0-59
Select the correct minute.
NATURAL DEFROST
YES / NO
YES = Natural defrost will be allowed
NO = Natural defrost will not be allowed
8 HOURS ADDITIONAL DATA:
YES / NO
YES = When the SROS is turned OFF, the Data Re-
corder will continue to record data for an additional 8
hours.
NO = When the SROS is turned OFF, the data Data
Recorder will stop recording data.
