4-OPERATINGINSTRUCTIONS
Proportionalswitchtype
1.Makethenecessarytoolconnectionsandthen,using
ahexagonalwrench,openthesupplyvalveslocated
atthetipofthearm,left-handandright-handside.
VOHLGR-0168
2.Switch(1)locatedonthefrontright-handconsole,cor-
respondingtothehydraulicbreaker.
Everytimetheswitch(1)ispressed,oneofthediffer-
enttypesofowpatternsrecordedforthepumpcan
beselected.Forowsettingmethod,refertopage
3-26.
VOHLGR-0029
3.Theiconoftheaccessoryassociatedwitheachtype
ofowdisplaysonthescreen.
010FD87FZ10
4.Afterswitch(1)hasbeenoperated,thesetowwillbe
displayedforasetamountoftime.
208F89D4Z11
