6-MAINTENANCE

Every1000hours

NOTE:Ifthefollowinglinkagepointsarenotequipped

withoriginalparts,thesepointsmustbelubricatedevery

50hours.

Armlink/connectingrodlinkages:(4)

NOTE:Ifanaccessoryotherthanthebucketisinstalled,

(hydraulichammer,etc.)thesepointsmustbelubricated

every10hours.

SMIL15CEXX536AB11

Bucketcylinderbottompin:(1)

8U6DVD-017A12

6-16
