CASE CONSTRUCTION CX160C - Adjusting the Tension

6-MAINTENANCE
Adjustingthetension
NOTE:Thisoperationistobecarriedoutafterthetension
hasbeenchecked.
Toincreasetension
1.Cleanthegreasettingadaptorandthegreasetting.
2.Connectthegreasepump.Injectgreasetoobtainthe
rightamountoftracktension.
Thevaluemustbebetween:280mm(11.0in)and
300mm(11.8in).
3.Removethegreasepumpandcleanthegreasetting.
4.RepeatSteps1to3fortheothertrack.
1V7EYE-0026
Toreducetension
1.Loosenthegreasettingadaptorbyaboutthreeturns
toallowgreasetoowoutofthecylinder.
WARNING
Pressurizeduidcanpenetratetheskinand
causesevereinjuries.
Thegreaseinthecylinderisunderhighpres-
sure.Neverloosenthegreasettingadaptor
completelyinordertospeeduptheowof
grease.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0261A
2.Assoonastherighttracktensionisobtained,tighten
theadaptor.
Thevaluemustbebetween:280mm(11.0in)and
300mm(11.8in).
3.Cleanthegreaseadaptorandttingandthenlower
theraisedtracktotheground.
4.RepeatSteps1to3fortheothertrack.
NOTICE:Ifthegreasettingadaptorisdamaged,grease
mayleakout.
Checktheconditionofthegreasettingadaptorregularly
andreplaceitifnecessary.
SMIL15CEXX766AA7
6-53
