6-MAINTENANCE

Trackpadscrewtighteningtorque

NOTE:Regularlycheckthetighteningofthescrews.

Donotusethemachinewiththetrackpadscrewsloose,

thescrewsmaycomeoffanddamagethetrack.

Thetighteningtorqueofthescrewsmustbe:

755-853N·m(556.9-629.1lbft)

UEBLNV-0018

NOTE:Followtheprescribedorder.

UEBLNV-0029

6-54
