VeriFast
TM
MicroView 1.0 – User Manual – Version 1.9
47
Troubleshooting Quick Guide
• Before starting to troubleshoot the MicroView, ensure that the
equipment is disconnected from all sources of power and is in the
lockout state.
• Before turning ON the equipment, make sure all components are
assembled properly.
Table 11 – Troubleshooting the VeriFast™ MicroView 1.0
MicroView not running
Is the MicroView unit
connected / wired
properly?
Check the power source for correct voltage
(see Technical Specifications section on
Check the power connection on the Power /
Schedule / Status Port and ensure the device
Is the MicroView unit
in Teach Mode?
Ensure the MicroView unit is either on the Run
page or has gone into screensaver mode for
proper operation. When the unit is on a Teach
page, the device outputs are disabled.
Output pins not
turning ON
No schedule selected
When there is no selected schedule, the
MicroView will not operate. Ensure that the
Schedule pins are wired such that the binary
value is between 1 and 16.
Channel Bypassed
If a channel is bypassed, the MicroView will
not operate the schedule on that channel, and
no outputs will turn ON for that Output Port,
except the Bypass signal.
Is the MicroView unit
in Teach Mode?
Ensure the MicroView unit is either on the Run
page, or has gone into screensaver mode for
proper operation. When the unit is on a Teach
page, the device outputs are disabled.
Consumable worn /
changed
Re-teach positions as necessary.
reading
(e.g., moving the sensor
1 mm and device
Improper setup
scaling.
MicroView requires proper scaling for each
device connected to it. For proper scaling
instructions, see Scaling Screen section on
page 36.
Password not working Incorrect password
Reset MicroView unit to factory default
password. See section Resetting Passwords
and Settings to Factory Defaults on page 46.
To Next Page
