CenterLine VeriFast MicroView 1.0 User Manual

20
VeriFast
TM
MicroView 1.0 – User Manual – Version 1.9
10-port Dual Device Port Configuration
Port on MicroView /
Connected Device
Pin Function
Device 1, Device 2 Ports (Inputs)
VeriFast™ LVDT
1
Primary Coil 1
2
Primary Coil 2
3
Secondary Coil 1
4
Secondary Coil 2
5
Shield
Analog / Laser
1
+24 VDC
2
No Connection
3
0 VDC
4
No Connection
5
0-10 VDC Analog Signal
Balluff LPT
Device Type
1
No Connection
2
0 VDC
3
No Connection
4
No Connection
5
0-10 VDC Analog Signal
6
Ground (0 VDC)
7
+24 VDC
8
No Connection
Output Device Ports and Power / Schedule / Status Port
CN-1
VeriFast™ LVDT
1
+24 VDC
2
Device 1, Weld Position
3
0 VDC
4
Device 1, Pin Extended
Analog / Laser
1
+24 VDC
2
Device 1, P2
3
0 VDC
4
Device 1, P1
Balluff LPT
1
+24 VDC
2
Device 1, Weld Position
3
0 VDC
4
Device 1, Gun Opened
CN-2
VeriFast™ LVDT
1
+24 VDC
2
Device 1, Pin Retracted
3
0 VDC
4
Device 1, Set Down
Analog / Laser
1
+24 VDC
2
Device 1, P4
3
0 VDC
4
Device 1, P3
Balluff LPT
1
+24 VDC
2
Device 1, Double Nut
3
0 VDC
4
Device 1, No Nut
