CenterLine VeriFast MicroView 1.0 User Manual

VeriFast
TM
MicroView 1.0 – User Manual – Version 1.9
21
Port on MicroView /
Connected Device
Pin Function
CN-3
VeriFast™ LVDT
1
Not Connected
2
Device 2, Weld Position
3
Not Connected
4
Device 2, Pin Extended
Analog / Laser
1
Not Connected
2
Device 2, P2
3
Not Connected
4
Device 2, P1
Balluff LPT
1
Not Connected
2
Device 2, Weld Position
3
Not Connected
4
Device 2, Gun Opened
CN-4
VeriFast™ LVDT
1
Not Connected
2
Device 2, Pin Retracted
3
Not Connected
4
Device 2, Set Down
Analog / Laser
1
Not Connected
2
Device 2, P4
3
Not Connected
4
Device 2, P3
Balluff LPT
1
Not Connected
2
Device 2, Double Nut
3
Not Connected
4
Device 2, No Nut
CN-5
VeriFast™ LVDT / Analog /
Laser / Balluff LPT
1
Not Connected
2
Teach Mode
3
Not Connected
4
Run Mode
CN-6
VeriFast™ LVDT / Analog /
Laser / Balluff LPT
1
Not Connected
2
Device 2, Bypassed
3
Not Connected
4
Device 1, Bypassed
CN-7
VeriFast™ LVDT / Analog /
Laser / Balluff LPT
1
Not Connected
2
Schedule 2
3
Not Connected
4
Schedule 1
CN-8
VeriFast™ LVDT / Analog /
Laser / Balluff LPT
1
Not Connected
2
Schedule 8
3
Not Connected
4
Schedule 4
