Setup Scaling
After the MicroView is mounted and wired, the necessity of performing a setup procedure (called
“Scaling”) depends on the type of the measuring unit that will be used during the operation process
(i.e., counts, mm, inch):
• Using Counts during operation – No setup (scaling) of the MicroView is necessary.
• Using mm or inch during operation – Setup (scaling) of the MicroView is required in
order for the unit to provide accurate readings during operation.
Scaling must be performed for each new device that is connected to the MicroView. For
instructions on how to perform the scaling procedure, refer to sub-section Scaling Screen on
page 36. To access the scaling screen, see Figure 9 – VeriFast™ MicroView Screens on page 28.
