Chamberlain CAPXL - INTRODUCTION; CAPXL; CAPXLV Overview

4
PRE-INSTALL NETWORKINSTALL ACCESS CONTROLINTRODUCTION
CAPXL / CAPXLV Overview
CAPXL/CAPXLV are cloud based access control solutions for residential communities. CAPXLV includes an integrated video camera
enabling advanced video features.
ON
POWER/INTERNET BOARD
SENSOR BOARD
CONTROL BOARD
DOOR BOARD 1
(Doors 1 & 2)
LOOP DETECTOR
BOARD MOUNTING
LOCATION
(CAPXL / CAPXLV) Integrated video camera
Security+ 2.0
®
RADIO ANTENNA
Wi-Fi
®
ANTENNA
POSTAL LOCK
SWITCH
DISPLAY (TOUCHSCREEN)
SPEAKER
LOCK
POSTAL LOCK
LOCATION
PROXIMITY READER LOCATION
CAMERA WINDOW
MICROPHONE
RADIO ANTENNA
CONNECTION
Wi-Fi
®
ANTENNA
CONNECTION
DOOR BOARD 2
(Doors 3 & 4)
MAIN EARTH
GROUND LOCATION
NOTE: Install only the
Liftmaster camera.
No other camera will
be compatible.
