Power/Internet Board Overview
ON
DISPLAY
Display
RADIO ANTENNA
Connection to Control Board
Door Board 1
Door Board 2
ETHERNET
POWER
Power Connection
for Control Board
Sensor Board
Postal Lock
Speaker
Audio
In
Dip Switches
(Switch #1 is used to
toggle Admin Mode.)
LOOP BOARD
