Chamberlain CAPXL - Carton Inventory; Tools Needed

7
Tools Needed
• PH2 Phillips Screwdriver
• Precision 1/8" Flat or PH0 Phillips Screwdriver
• 1/4" Nut Driver
• Drill/Driver
• 7/64" Drill Bit
• Hammer Drill Bits for Drill/Driver
• RJ45 Crimping Pliers
• Multimeter
• Measuring tape
• Conduit Bender
• Conduit Cutter/Reamer
• Hack Saw
• Center Punch Tool
• Hammer
PROVIDED (NOT SHOWN)
• Installation Manual
• Quickstart Guide
CAPXL/CAPXLV
Carton Inventory
PRE-INSTALL NETWORKINSTALL ACCESS CONTROLINTRODUCTION
Power Supply
Goose-neck Gasket
Keys (2)
Ferrite Core
S10K30MOV
(Metal Oxide Varistor)(4)
1N4005 Diode Kit (4)
Radio Antenna (Security+ 2.0
®
)
and Cable
Wi-Fi
®
Antenna and Cable
Additional Tools Recommended
• Network LAN Cable Tester
• Wi-fi Analyzer App (smart phone app)
• Network Analyzer software
