Mount a Single Station Bracket and CMK
23
9. Slowly lift the CMK into position with the slot at the
bottom of the CMK sliding onto the knob at the
bottom of the pedestal.
Note: The ropes will rise as the weights inside the
CMK lower. Guide the ropes to the top as you slowly
lift the CMK.
10. Hold the CMK against the back of the pedestal while
aligning the four screws coming through the bracket
and pedestal into the corresponding holes in the
CMK.
Note: The spacer on the pedestal should slide into the ridges on the CMK.
11. While holding the bracket and CMK in place, tighten the four screws using the 7/16 in socket.
Proceed to section 9 to mount the station.
