Operating Principles Edge Maxx
5-4
Electrical Panel
All power system components are located in
the right endframe (Figure 5-3). The table on the
next page provides an explanation of each item
indicated in the picture. The page after shows
control relays not called out in this picture.
CON1
CR31
INV1
CON2
INV2
INV4INV3
Figure 5-3: Components in the electrical panel.
MP6
MP7
INV6INV5
T3
CB3
CB4
DSC1
SERVO
MP8
MP10
MP11
CB5
CB6
CR40
CR39
CR32
CON3
CON4
PWS1
PWS2
FILT1
T4
CREO
CB10
SVO
CON8A
CON8B
MP12
CREI
To Next Page
