Edge Maxx Operating Principles
5-5
ELECTRICAL PANEL COMPONENTS
Schematic Description
CB3 Circuit Breaker - T3 24VAC Control Circuit/SERVO Controller
CB4 Circuit Breaker - PWS1 24VAC Output Circuit
CB5 Circuit Breaker - PWS2 24VAC Output Circuit
CB6 Circuit Breaker - T4 Florescent Light
CB10 Circuit Breaker - 24VDC Fault Circuit
CON1 Contactor - Left and Right Inlet Motors (INV1/INV2)
CON2 Contactor - Left and Right Transfer Motors (INV3/INV4)
CON3 Contactor - Left and Right Lower Spread Motors/Exit Motor (INV5/INV6)
CON4 Contactor - Upper Spreader ServoMotor
CON8A/8B Contactor - Easi-Glide Motor Forward/Reverse (option)
CR31 Control Relay - Left Floor Motor (Transfer Section)
CR32 Control Relay - Right Floor Motor (Transfer Section)
CR39 Control Relay - Center Floor Motor (Transfer/Reject Sections)
CR40 Control Relay - (Not Used)
CREI Control Relay - Interconnect Stop Circuit Input Signal (option)
CREO Control Relay - Interconnect Stop Circuit Output Signal (option)
DSC1 Main Disconnect Switch
FILT1 Filter - Incoming Power
INV1 Inverter - Left Inlet Conveyor Motor
INV2 Inverter - Right Inlet Conveyor Motor
INV3 Inverter - Left Transfer Motor
INV4 Inverter - Right Transfer Motor
INV5 Inverter - Exit Conveyor Motor
INV6 Inverter - Lower Spreader Motor
MP6 Motor Protector - Left Lower Spreader Motor
MP7 Motor Protector - Right Lower Spreader Motor
MP8 Motor Protector - Left and Right Floor Motors (Reject Section)
MP10 Motor Protector - Bottom Floor Motor (Reject Section)
MP11 Motor Protector - Center Floor Motor (Reject Section) (not used)
MP12 Motor Protector - Easi-Glide Motor (option)
PWS1 Power Supply - 24VDC Output Circuit (P01, DC Start/Control Power)
PWS2 Power Supply - 24VDC Output Circuit (P02/P03, DC Start/Control Power)
SERVO Controller - Upper Spreader Servo Motor
SVO I/O Board - Spreader Servo
T3 Transformer - 24VAC Start/Control Circuit
T4 Transformer - Florescent Light
