The tester returns 2.000000E+00.
Description: The returned result indicates the time of voltage fall in CH5 STEP 4
for Address 0 host is 2.0sec.
[:SOURce]:SAFety[:CHANnel]<m>:RESult:STEP<n>:TIME[:ELAPsed]: RAMP?
It queries the time of voltage ramp in specified STEP when the Screen sets to On. The
format of variable <m> at the end of [:CHANnel] is 3 digits. The first digit is Frame index
in the range of 0~9 and the last two digits are Channel index in the range of 01~10
(19020/19021/19022) or 01~04(19020-4/19021-4/19022-4). When the variable is
ignored it is 001 to indicate Channel 1 of the Master.
Example: Input the command SAF:CHAN005:RES:STEP1:TIME:RAMP?
The tester returns 5.000000E-01.
Description: The returned result indicates the time of voltage ramp in CH5 STEP 1
for Address 0 host is 0.5sec.
[:SOURce]:SAFety[:CHANnel]<m>:RESult:STEP<n>:TIME[:ELAPsed] [:TEST]?
It queries the test time of specified STEP when the Screen sets to On. The format of
variable <m> at the end of [:CHANnel] is 3 digits. The first digit is Frame index in the
range of 0~9 and the last two digits are Channel index in the range of 01~10
(19020/19021/19022) or 01~04(19020-4/19021-4/19022-4). When the variable is
ignored it is 001 to indicate Channel 1 of the Master.
Example: Input the command SAF:CHAN005:RES:STEP2:TIME?
The tester returns 3.000000E+00.
Description: The returned result indicates the test time required in CH5 STEP 2 for
Address 0 host is 3.0sec.
[:SOURce]:SAFety:FRAMe<f>:RESult:STEP<n>[:JUDGment]?
It queries the judgment of specified STEP for all channels of a Frame when the Screen
sets to On. The range of variable <f> at the end of FRAMe<f> command is 0~9 that
indicates the Frame address. When <f> is ignored the default is 1 it indicates to query
the judgment results of all channels for Slave 1. Return format: Ch1 Result, Ch2
Result, ..., Ch10 Result. The table below lists the definition of Code:
Code of Test Result
Mode
AC
DC
IR
OSC
ALL
Code
HEX
DEC
HEX
DEC
HEX
DEC
HEX
DEC
HEX
DEC
STOP
70
112
TESTING
73
115
PASS
74
116
HIGH FAIL
21
33
31
49
41
65
LOW FAIL
22
34
32
50
42
66
ARC FAIL
23
35
33
51
OCP
24
36
34
52
44
68
64
100
SHORT FAIL
61
97
OPEN FAIL
62
98
Example: Input the command SAF:FRAM0:RES:STEP3?
The tester returns 116,116,116,116,116,116,116,116,116,116.
Description: The returned result indicates the judgment result of STEP 3 for all
Channels of Address 0 host is PASS.
