Descriptions of Panel
4-15
TEST
MODE
SOURCE
LIMIT
RES.
OFFSET
01
GB
25.00 A
100.0 mΩ
Get Cs
PAGE UP
PAGE DOWN
SCANNER-1
1 2 3 4 5 6 7 8
GB
GB CONTACT 2.3s
Remote
Lock
Offset
Error
Figure 4-7
4. After GB CONTACT, the timer counts down for three seconds (Start Wait setting time),
and then the test starts, as shown in Figure 4-8.
TEST
MODE
SOURCE
LIMIT
RES.
OFFSET
01
GB
25.00 A
1.9 mΩ
Get Cs
PAGE UP
PAGE DOWN
SCANNER-1
1 2 3 4 5 6 7 8
GB
TEST TIME: 1.3s
Remote
Lock
Offset
Error
Figure 4-8
5. When the test ends, if the DUT PASSes, the display will show:
TEST
MODE
SOURCE
LIMIT
RES.
OFFSET
01
GB
25.01 A
1.9 mΩ
Get Cs
PAGE UP
PAGE DOWN
SCANNER-1
1 2 3 4 5 6 7 8
GB
WAIT GB OPEN..
Remote
Lock
Offset
Error
Figure 4-9
