GPIB Operation Description (Option)
Return message “2.000000E+00”
Description: Return message “2.000000E+00” means test ramps to
setting voltage needed time of the main unit STEP 2 is
2.0 sec.
[: TEST] <numeric_
value>
: SOURce: SAFEty: STEP: DC: TIME: TEST
This command sets selected STEP which test needed time.
Example: Input command “SAFE:STEP 2:DC:TIME 1”
Description: This command means test needed time of the main unit
STEP 2 is set to 1.0 sec.
[: TEST]?
: SOURce: SAFEty: STEP: DC: TIME: TEST?
This command queries selected STEP which test needed time.
Example: Input command “SAFE:STEP 2:DC:TIME?”
Return message “1.000000E+00”
Description: Return message “1.000000E+00” means test needed
time of the main unit STEP 2 is 1 sec.
: FALL <numeric
value>
: SOURce: SAFEty: STEP: DC: TIME: FALL
This command sets selected STEP which setting voltage value fall
to zero needed time.
Example: Input command “SAFE: STEP 2: DC: TIME: FALL 1.5”
Description: This command means setting voltage value fall to zero
needed time of the main unit STEP 2 is set to 1.5 sec.
: FALL?
: SOURce: SAFEty: STEP: DC: TIME: FALL?
This command queries selected STEP which setting voltage value
fall to zero needed time.
Example: Input command “SAFE: STEP 2: DC: TIME: FALL?”
Return message “1.500000E+00”
Description: Return message “1.500000E+00” means voltage value
fall to zero needed time of the main unit STEP 2 is
1.5 sec.
: DWELl <numeric
value>
: SOURce: SAFEty: STEP: DC: TIME: DWELl
This command sets selected STEP which dwell needed time.
Example: Input command “SAFE: STEP 2: DC: TIME: DWEL 2.5”
Description: This command means dwell needed time of the main
unit STEP 2 is set to 2.5 sec.
: DWELl?
: SOURce: SAFEty: STEP: DC: TIME: DWELl?
This command queries selected STEP which setting dwell time.
Example: Input command “SAFE: STEP 2: DC: TIME: DWEL?”
Return message “2.500000E+00”
Description: Return message “2.500000E+00” means dwell time of
the main unit STEP 2 is 2.5 sec.
: CHANnel
5-25
