HIPOT Tester 19051/19052/19053/19054 User’s Manual
leakage current low limit.
Example : Input command “SAFE:STEP 2:DC:LIM:LOW?”
Return message “1.000000E-06”
Description: Return message “1.000000E-06” means DC withstand
voltage leakage current low limit value of the main unit
STEP 2 is 0.001mA.
: ARC
[: LEVel] <numeric_value>
: SOURce: SAFEty: STEP: DC: LIMit: ARC: LEVel
This command sets selected STEP which ARC checking value.
Example: Input command “SAFE:STEP 2:DC:LIM:ARC 0.0025”
Description: This command means ARC checking value of the main
unit STEP 2 is set to 2.5mA.
[: LEVel]?
: SOURce: SAFEty: STEP: DC: LIMit: ARC: LEVel?
This command queries selected STEP which ARC checking value.
Example: Input command “SAFE:STEP 2:DC:LIM:ARC?”
Return message “2.500000E-03”
Description: Return message “2.500000E-03” means ARC
checking value of the main unit STEP 2 is 2.5mA.
: CLOW <boolean>|ON|OFF
: SOURce: SAFEty: STEP: DC: CLOW
This command sets selected STEP detect if charge current over low or
not.
Example: Input command “SAFE:STEP 2:DC:CLOW ON”
Description: This command means detection charge current over low
function of the main unit STEP 2 is set to ON.
: CLOW?
: SOURce: SAFEty: STEP: DC: CLOW?
This command queries selected STEP detect if charge current over low
or not.
Example: Input command “SAFE:STEP 2:DC:CLOW?”
Return message “1”
Description: Return message “1” means detection charge current over
low function of the main unit STEP 2 is ON.
: TIME
: RAMP <numeric_
value>
: SOURce: SAFEty: STEP: DC: TIME: RAMP
This command sets selected STEP which test ramps to setting
voltage needed time.
Example: Input command “SAFE: STEP 2: DC: TIME: RAMP 2”
Description: This command means test ramps to setting voltage
needed time of the main unit STEP 2 is set to 2.0 sec.
: RAMP?
: SOURce: SAFEty: STEP: DC: TIME: RAMP?
This command queries selected STEP which test ramps to setting
voltage needed time.
Example: Input command “SAFE: STEP 2: DC: TIME: RAMP?”
5-24
