Chroma 63200A Series User Manual

Remote Operation
4-61
Setting Syntax: STATus:CSUMmary:ENABle<space><NR1>
Setting Parameters: <NR1>, 0 ~ 1023, Unit = None
Bit Configuration of Channel Summary Register
Bit Position
9
8
7
6
5
4
3
2
1
0
Channel
10
9
8
7
6
5
4
3
2
1
Bit Weight
512
256
128
64
32
16
8
4
2
1
Setting Example: STAT:CSUM:ENAB 3
Query Syntax: STATus:CSUMmary:ENABle?
Return Parameters:<NR1>
Query Example: STAT:CSUM:ENAB? Return the setting of Channel
Summary Enable register.
Return Example: 3
STATus:CSUMmary:EVENt?
Type: Channel-Specific
Description: Indicate all channels of which an enabled STAT:CHAN Event
has occurred since last time the register was read.
Query Syntax: STATus:CSUMmary:EVENt?
Return Parameters:<NR1>
Query Example: STAT:CSUM:EVEN? Return the value of the Channel
Summary Event register.
Return Example: 3
STATus:QUEStionable:CONDition?
Type: Channel-Specific
Description: Real-time ("live") recording of Questionable data
Query Syntax: STATus:QUEStionable:CONDition?
Return Parameters:<NR1>
Query Example: STAT:QUES:COND? Return the channel status.
Return Example: 6
STATus:QUEStionable:ENABle
Type: Channel-Specific
Description: Mask to select which bit on the Event register is allowed to be
summed into the QUES bit for the Status Byte register.
Setting Syntax: STATus:QUEStionable:ENABle<space><NR1>
Setting Parameters:
Bit Configuration of Questionable Status Register
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Condition
MAX_
LIM
RMT
_INH
VCC
FAN
SYNC
OTP
OPP3
OPP2
OPP1
OCP3
OCP2
OCP1
REV
OV2
OV1
Bit Weight
32768
16384
8192
4096
2048
1024
512
256
128
64
32
16
8
4
2
1
Setting Example: STAT:QUES:ENAB 24
Query Syntax: STATus:QUEStionable:ENABle?
Return Parameters:<NR1>, 0 ~ 65535, Unit = None
Query Example: STAT:QUES:ENAB Return the setting of the Status
Questionable Enable register.
Return Example: 24
