Chroma 63200A Series User Manual

High Power Electronic Load 63200A Series Operation & Programming Manual
4-6
Chapter 5.
Standard Event Status Event Register
Bit Position
7
6
5
4
3
2
1
0
Condition
PON
0
CME
EXE
DDE
QYE
0
OPC
Bit Weight
128
64
32
16
8
4
2
1
Query Syntax: *ESR?
Return Parameters: <NR1>
Query Example: *ESR? Return the Standard Event Status register readings.
Return Example: 48
*IDN? Identification Query
Type: System Interface
Description: This query requests the host to identify itself.
Query Syntax *IDN?
Return Parameters:<aard>
Query Example: *IDN?
String Information
Chroma ATE Inc. Manufacture
63205A-150-500 Model
63205A000001 Serial number
1.00 HOST‘s version of F/W
1.00 HOST‘s version of FPGA
1.00 HOST‘s version of PCB
Return Example: Chroma ATE Inc.,63205A-150-500,63205A000001,1.00,1.00,1.00
*OPC Operation Complete Command
Type: Device Status
Description: This command causes the interface to set the OPC bit (bit 0) of the
Standard Event Status register when the Electronic Load has
completed all pending operations.
Setting Syntax: *OPC
Setting Parameters: nil
*OPC? Operation Complete Query
Type: Device Status
Description: This query returns an ASCII “1” when all pending operations are
completed.
Query Syntax: *OPC?
Return Parameters:<NR1>
Query Example: 1
*RCL Recall Instrument State Command
Type: Device Status
Description: This command restores the electronic load to a state that was
previously stored in memory with the *SAV command to the
specified location (see *SAV).
Setting Syntax: *RCL<space><NR1>
Setting Parameters:<NR1>, 0 ~ 10, 0:Factory default file, 1~10:User define file
Setting Example: *RCL 5
