When the LaneSense system senses the lane has
been approached and is in a lane departure situa-
tion, the left inside lane line flashes yellow (on/off)
while the left outside line remains solid yellow. The
LaneSense telltale
changes from solid yellow to
flashing yellow. At this time torque is applied to the
steering wheel in the opposite direction of the lane
boundary.
For example: If approaching the left side of the lane
the steering wheel will turn to the right.
NOTE:
The LaneSense system operates with similar behavior
for a right lane departure.
CHANGING LANESENSE STATUS
The LaneSense system has settings to adjust the inten-
sity of the torque warning and the warning zone sensi-
tivity (Early/Medium/Late) that you can configure
through the Uconnect system
page 169.
NOTE:
•
When enabled the system operates above 37 mph
(60 km/h) and below 112 mph (180 km/h).
•
The warnings are disabled with use of the turn
signal.
•
The system will not apply torque to the steering
wheel whenever a safety system engages (Anti-Lock
Brakes, Traction Control System, Electronic Stability
Control, Forward Collision Warning, etc.).
PARKVIEW REAR BACK UP CAMERA
The ParkView Rear Back Up Camera allows you to see
an on-screen image of the rear surroundings of your
vehicle whenever the gear selector is put into REVERSE.
The image will be displayed on the touchscreen display
along with a caution note “Check Entire Surroundings”
across the top of the screen. After five seconds, this
note will disappear. The ParkView Rear Back Up Cam-
era is located on the rear of the vehicle above the rear
license plate.
NOTE:
The ParkView Rear Back Up Camera has programmable
modes of operation that may be selected through the
Uconnect system
page 169.
When the vehicle is shifted out of REVERSE with cam-
era delay turned off, the rear camera mode is exited
and the previous screen appears.
When the vehicle is shifted out of REVERSE with cam-
era delay turned on, the camera image will continue to
be displayed for up to 10 seconds unless the vehicle
speed exceeds 8 mph (13 km/h), the vehicle is shifted
into PARK, or the ignition is placed in the OFF position.
A touchscreen X button to disable the camera image is
made available when the vehicle is not in REVERSE
gear. Display of the camera image after shifting out of
REVERSE can be disabled through the camera settings
menu with the Uconnect system.
When enabled, active guidelines are overlaid on the
image to illustrate the width of the vehicle and its pro-
jected backup path based on the steering wheel
position.
Different colored zones indicate the distance to the rear
of the vehicle.
The following table shows the approximate distances
for each zone:
Zone Distance To The Rear Of The Vehicle
Red 0-1ft(0-30cm)
Yellow 1 ft - 6.5 ft (30 cm - 2 m)
Green 6.5 ft or greater (2 m or greater)
Lane Drift With Solid Yellow Line/Solid Yellow Telltale
Lane Approached With Flashing Yellow Line/Flashing
Yellow Telltale
154 STARTING AND OPERATING
