NOTE:
If snow, ice, mud, or any foreign substance builds up on
the camera lens, clean the lens, rinse with water, and
dry with a soft cloth. Do not cover the lens.
WARNING!
Drivers must be careful when backing up even when
using the ParkView Rear Back Up Camera. Always
check carefully behind your vehicle, and be sure to
check for pedestrians, animals, other vehicles,
obstructions, or blind spots before backing up. You
are responsible for the safety of your surroundings
and must continue to pay attention while backing up.
Failure to do so can result in serious injury or death.
CAUTION!
•
To avoid vehicle damage, ParkView should only be
used as a parking aid. The ParkView camera is
unable to view every obstacle or object in your
drive path.
•
To avoid vehicle damage, the vehicle must be
driven slowly when using ParkView to be able to
stop in time when an obstacle is seen. It is recom-
mended that the driver look frequently over his/
her shoulder when using ParkView.
SURROUND VIEW CAMERA SYSTEM —
IF EQUIPPED
Your vehicle may be equipped with the Surround View
Camera system that allows you to see an on-screen
image of the surroundings and Top View of your vehicle
whenever the gear selector is put into REVERSE or a
different view is selected through the touchscreen but-
tons. The Top View of the vehicle will show which doors
are open. The image will be displayed on the touch-
screen display along with a caution note “Check Entire
Surroundings” across the top of the screen. After five
seconds, this note will disappear. The Surround View
Camera system is comprised of four sequential cam-
eras located in the front grille, rear liftgate and side
mirrors.
NOTE:
The Surround View Camera system has programmable
settings that may be selected through the Uconnect
system
page 169.
Press this button on the touchscreen to
enter the Surround View Camera menu in
the Uconnect system.
When the vehicle is shifted into REVERSE,
the Rear View and Top View is the default view of the
system.
When the vehicle is shifted out of REVERSE with cam-
era delay turned on, the camera image will continue to
be displayed for up to 10 seconds unless the vehicle
speed exceeds 8 mph (13 km/h), the vehicle is shifted
into PARK, or the ignition is placed in the OFF position.
There is a touchscreen X button to disable the display
of the camera image.
When the vehicle is shifted out of REVERSE with cam-
era delay turned off, the Surround View system is exited
and the last known screen appears again.
Whenever the Rear View Camera image is activated
through the Back Up Camera button in the Controls
menu, and the vehicle speed is greater than, or equal
to, 8 mph (13 km/h), a display timer for the image is
initiated. The image will continue to be displayed until
the display timer exceeds 10 seconds.
NOTE:
•
If the vehicle speed remains below 8 mph
(13 km/h), the Rear View Camera image will be dis-
played continuously until deactivated via the touch-
screen X button, the transmission is shifted into
PARK, or the ignition is placed in the OFF position.
•
The touchscreen X button to disable display of the
camera image is made available ONLY when the
vehicle is not in REVERSE.
When enabled, active guidelines are overlaid on the
image to illustrate the width of the vehicle, including
the side view mirrors and its projected back up path
based on the steering wheel position.
Different colored zones indicate the distance to the rear
of the vehicle.
The following table shows the approximate distances
for each zone:
Zone Distance To The Rear Of The Vehicle
Red 0-1ft(0-30cm)
Yellow 1 ft - 6.5 ft (30 cm - 2 m)
Green 6.5 ft or greater (2 m or greater)
STARTING AND OPERATING 155
4
