NOTE:
After use, the Portable Charging Cordset (EVSE) should
be placed in the storage bag and put back in the cargo
area storage bin if equipped. If the Portable Charging
Cordset (EVSE) will be left outside the vehicle, be sure
to protect the connection end from moisture, dirt, and
debris accumulation and contamination.
NOTE:
The Portable Charging Cordset (EVSE) is used for AC
Level 1 charging only.
WARNING!
IMPORTANT SAFETY INSTRUCTIONS PERTAINING TO
A RISK OF FIRE OR ELECTRIC SHOCK: This publica-
tion contains important instructions and warnings
that should be followed during charging operations.
Failure to follow these warnings and instructions can
result in electrical shock and fire which can cause
death or serious injury.
•
Read this entire publication before using the Por-
table Charging Cordset (EVSE).
(Continued)
WARNING!
•
Do not put fingers or objects into the Portable
Charging Cordset (EVSE) connector.
•
Do not use the Portable Charging Cordset (EVSE) if
the flexible power cord is frayed, broken, has
cracked insulation, or any other signs of damage.
•
Do not use the Portable Charging Cordset (EVSE) if
the enclosure or the connector is broken, cracked,
open, or shows any other indication of damage.
•
Do not use the Portable Charging Cordset (EVSE)
with an extension cord or plug adapters.
•
The Portable Charging Cordset (EVSE) may attempt
to reset and run after a power interruption.
•
There are no user serviceable parts inside the Por-
table Charging Cordset (EVSE). Do not attempt to
repair or service the Portable Charging Cordset
(EVSE) yourself – personal injury may result.
•
When using a charging station with the Portable
Charging Cordset (EVSE) attached, ensure the
charging station’s cable is not visibly damaged
before plugging into the vehicle.
•
Do not allow children to operate the Portable
Charging Cordset (EVSE). Adult supervision is man-
datory when children are in proximity to the charge
station that is in use.
•
Do not use a charge station or vehicle charge inlet
that is worn or damaged with the AC Level 2 charg-
ing cable. Plugging into worn or damaged recep-
tacles may cause damage to the Portable Charging
Cordset (EVSE) and vehicle.
(Continued)
WARNING!
•
Ensure that the Portable Charging Cordset (EVSE)
is always stored in a safe place. Do not expose the
EVSE J1772 vehicle connector to rain or wet condi-
tions. Avoid allowing water or other liquids to pour
or drip onto the vehicle connection end of the
J1772 EVSE connector. If water penetrates the
electrical device, the risk of electrical shock
increases. Ensure that all plugs and cables are
free of moisture before using the Portable Charg-
ing Cordset (EVSE).
•
In a collision, a loose Portable Charging Cordset
(EVSE) in the vehicle could cause injury. It could fly
around in a sudden stop and strike someone in the
vehicle. Do not store the Portable Charging Cordset
(EVSE) on the cargo load floor, or in the passenger
compartment.
•
The Portable Charging Cordset (EVSE) has been
tested for use in temperatures ranging from -40°F
to 122°F (-40°C to 50°C).
•
The Portable Charging Cordset (EVSE) should be
stored at temperatures between -40°F and 176°F
(-40°C and 80°C).
•
SAVE THESE INSTRUCTIONS.
AC LEVEL 2 CHARGING
(240 VOLT, 32 AMP)
AC Level 2 (240 V) charging requires a 240 V, Level
2 Electric Vehicle Supply Equipment (EVSE) charging
station. A 32 Amp Level 2 EVSE for home installation is
recommended. The Level 2 EVSE connects to a 40 Amp
circuit breaker and delivers 32 Amp maximum to the
vehicle.
Cargo Area Storage Bin
