Cavity Cartridge Fuse Blade Fuse Description
*If Equipped
F97 – 10 Amp Red Airbag
F98 – 15 Amp Blue Left HID Headlamp *
F99 30 Amp Pink – Trailer Tow Elect Brake Module *
F100 – 10 Amp Red
Headlamp Level / RR Camera / Blindspot
/ Humidity SNSR / In Car Temp SNSR /
Headlamp SW *
Circuit Breakers
CB1 25 Amp Power Seats (Driver)
CB2 25 Amp * Power Seats (Pass)
CB3 25 Amp
FRT PWR Window W/O Door Nodes + RR
PWR Window Lockout
30 Amp mini fuse is substituted for 25 Amp Circuit Breaker.
BULB REPLACEMENT
Replacement Bulbs, Names, And Part Numbers
In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers.
NOTE:
Your vehicle is equipped with LED lamps. For replacement of LED lamps, see an authorized dealer.
Interior Bulbs — Halogen
Interior Bulbs
Lamps Bulb Number
Visor Vanity Lamps 6501966
NOTE:
Your vehicle is equipped with LED lamps. For replacement of LED lamps, see an authorized dealer.
SERVICING AND MAINTENANCE 289
8
