Exterior Bulbs — Halogen
Exterior Bulbs
Lamps Bulb Number
Front Turn Signal Lamp WY21W / 7440NA
Front Side Marker Lamp W3W / 2821
Rear Side Marker Lamp W3W / 2821
Replacing Exterior Bulbs
FRONT TURN SIGNAL LAMP
See the following steps to replace:
1. Open the hood.
2. Twist the front turn signal lamp socket assembly
counterclockwise, and then remove the front turn
signal lamp assembly from the lamp housing.
3. Pull the bulb out of the socket and insert the
replacement bulb.
4. Install the front turn signal lamp socket assembly
into the housing, and rotate the front turn signal
lamp socket clockwise to lock it in place.
FRONT AND REAR SIDE MARKER LAMPS
See the following steps to replace:
1. Remove the three fasteners from the inner wheel
liner and carefully peel back liner for access.
2. Firmly grab the front side marker lamp socket and
rotate a quarter turn counterclockwise to remove it
from the lamp assembly.
3. Remove bulb from the front side marker lamp
socket and replace with a new bulb.
4. Install front side marker lamp socket in lamp assem-
bly and rotate a quarter turn clockwise to lock into
place.
5. Position the inner wheel liner in place and install the
three fasteners.
Front Turn Signal Lamp Socket
Inner Wheel Liner Fasteners
Front Side Marker Lamp Bulb Removal
290 SERVICING AND MAINTENANCE
