Locating The Upper Tether Anchorages
There are tether strap anchorages located
behind all second row seating positions. The
third row has a tether anchor on the 40%
seat for the right outboard position and in
the center of the 60% seat for either the center or left
outboard seating position. All tether anchorages are
located on the back of the seat, near the floor.
LATCH Anchorages (Second Row Anchorages Shown)
Eight Passenger Seating
LATCH Anchorages (Second Row Bench Anchorages
Shown) Seven Passenger Bench Seating
Tether Strap Anchorages (Second Row Bench Anchorage
Shown)
Tether Strap Anchorages (Second Row Seven Passenger
Quad and Stow ‘n Go Anchorage Shown)
Tether Strap Anchorages (Second Row Eight Passenger
Anchorage Shown)
SAFETY 231
