Cavity Cartridge Fuse Blade Fuse Description
*If Equipped
F09 – 25 Amp Clear Amplifier / Active Noise Control *
F10 – – Not Populated
F11 – – Not Populated
F12 – 5 Amp Tan Battery Sensor (IBS)
F13 – 10 Amp Red ECM (S) *
F14 – 10 Amp Red ECM
F15 40 Amp Green – CBC / Power Locks
F16 – 20 Amp Yellow ECM
F17 30 Amp Pink – Starter
F18 40 Amp Green – CBC / EXT LIGHTS
F19 25 Amp Clear – 2nd Row Folding Seats Solenoid LT *
F20 – 10 Amp Red A/C Compressor Clutch
F21 25 Amp Clear – 2nd Row Folding Seat Solenoid RT *
F22 – – Not Populated
F23 – – Not Populated
F24 – 20 Amp Yellow RR Wiper
F25 – 10 Amp Red
Hands-Free Dr Mod / Active Grille Shutter
/ Pwr Mirror / VRM
F26 40 Amp Green – Front HVAC Blower Motor
F27 25 Amp Clear – RR Slide Door Module-RT *
F28 – 10 Amp Red
Diagnostic Port / USB+(IP) / Video USB
Port / Overhead DVD Player(Aftermarket)
F29 – – Not Populated
F30 – 15 Amp Blue Media HUB / Power Lumbar *
F31 – – Not Populated
F32 20 Amp Blue – ECM
