Cavity Cartridge Fuse Blade Fuse Description
*If Equipped
F56 – 10 Amp Red
Front and Rear HVAC Control Module /
Occupant Classification Module (OCM) /
Electronic Steering Lock (ESL) / ESP /
ESC
F57 – – Not Populated
F58 – 10 Amp Red
Drive Train Control Mod / Power Transfer
Unit *
F59 30 Amp Pink – Trailer Tow Receptacle *
F60 – 20 Amp Yellow Rear Cargo Pwr Outlet
F61 – 20 Amp Yellow Trailer Tow Right Stop/Turn *
F62 – 20 Amp Yellow Power Transfer Unit *
F63 – 20 Amp Yellow Trailer Tow Left Stop/Turn *
F64 – 15 Amp Blue RT HID Headlamp *
F65 – – Not Populated
F66 – 15 Amp Blue Cluster
F67 – 10 Amp Red
Haptic Lane Feedback Module (HALF) /
Parktronics System (PTS)/Drivers Assist
System Module (DASM)
F68 – – Not Populated
F69 – – Not Populated
F70 – – Not Populated
F71 – 20 Amp Yellow Horn
F72 – 10 Amp Red Heated Mirror *
F73 30 Amp Pink – Rear Defroster
F74 20 Amp Blue – Trailer Tow Backup Lights*
F75 – 5 Amp Tan Overhead Console / RR Center Stack
F76 – 20 Amp Yellow Uconnect / Center Display / Telematics
SERVICING AND MAINTENANCE 287
