GE+ ACDC Installation and operation manual v11
111 / 121
1. Voltage setpoints configuration where the user can introduce values for the global
configuration (parallel), channel U, V and W and the ramp.
2. Current setpoints configuration where the user can introduce values for the global
configuration (parallel), channel U, V and W and the ramp.
3. Power setpoints configuration where the user can introduce values for the global
configuration (parallel), channel U, V and W and the ramp.
4. Impedance setpoints configuration where the user can introduce values for the
global configuration (parallel), channel U, V and W and the ramp.
5. Pauses. It is necessary to add a Sleep in between rows. This will determinate the
duration of the setpoints introduced in the row right above the Sleep. Please note
that it is configured in milliseconds.
The minimum recommended value for a Sleep is 200ms.
The maximum and minimum values to be introduced in the parts 1, 2, 3, 4, and 5 depend
on the rated values of the equipment or the limits introduced by the user (chapter 1.6.
Limits).
To add or modify a row of the sequence follow the steps:
o Add Step: press this button once the parameters are introduced and the values
will appear the row in window B.
o Config Step: if there is any row of windows B that the user needs to modify,
double click directly to it in B and the values of that row will appear in the
corresponding part of A. For example, if the user makes a double click in a row
of B which is of power mode, the values of that row will appear in the part A3.
Then, the values can be modified in A3 and when the correct parameters are
introduced press Config Step. It will change the values of that selected row in B
with the new parameters introduced in A3.
- B: This part shows all the rows that configure the sequence. It allows to operate with
the rows, but no with the values of them. This window contains the following buttons:
o Move Row Up/Down. Select a row and press these buttons to move a row up or
down.
o Execute Sequence. Once the sequence is ready, press this button and the
converter will start the sequence.
o Open test. Another way to create a sequence instead of using the interface is
building it with an external programme and save it as a CSV file. This button
allows to open one of these files. The explanation of how to create this CSV file
is in the manual of the equipment.
o New test. This button will erase all the rows to begin a new sequence.
o Stop sequence. When the sequence is running and the user needs it to be
stopped, this button will do it and the setpoints will remain in the row of the
actual sequence.
