Cinergia GE+ - Page 42

GE+ ACDC Installation and operation manual v11
42 / 121
W1 Resistance W not used 10000 0
W2 Inductance W not used 10000 0
Voltage
source
Parallel Bipolar AC
U1 Voltage RMS setpoint not used 0 max voltage AC
U2 Phase angle -359º 0 359º
Current
source
Parallel Bipolar AC
U1 Current RMS setpoint min current AC 0 max current AC
U2 Phase angle -90º 0 90º
Power
source
Parallel Bipolar AC
U1 Active power min power 0 max power
U2 Reactive power min power 0 max power
Impedance
Parallel Bipolar AC
U1 Resistance not used 10000 0
U2 Inductance not used 10000 0
Voltage
source
Independent Unipolar
DC
U1 Voltage U DC setpoint not used 0 max voltage DC
V1 Voltage V DC setpoint not used 0 max voltage DC
W1 Voltage W DC setpoint not used 0 max voltage DC
Current
source
Independent Unipolar
DC
U1 Current U DC setpoint min current DC 0 max current DC
V1 Current V DC setpoint min current DC 0 max current DC
W1 Current W DC setpoint min current DC 0 max current DC
Power
source
Independent Unipolar
DC
U1 Power U DC setpoint min power 0 max power
V1 Power V DC setpoint min power 0 max power
W1 Power W DC setpoint min power 0 max power
Impedance
Independent Unipolar
DC
U1 Impedance U DC setpoint not used 10000 0
V1 Impedance V DC setpoint not used 10000 0
W1 Impedance W DC setpoint not used 10000 0
Voltage
source
Parallel Unipolar
DC U1 Voltage DC setpoint not used 0 max voltage DC
Current
source
Parallel Unipolar
DC U1 Current DC setpoint min current DC 0 max current DC
