71
The tables below list reader settings as well as symbology settings for the Long Range
Laser (LR) or Extra Long Range Laser (ELR) scan engine.
READER SETTINGS TABLE
LR/ELR Description Default
AIM Duration
0~255, in units of 1 second.
Enter 0 if aiming is not desired.
No aiming
Decode Time-out Set the maximum time for decoding to continue during a
scan attempt.
5~99, in units of 0.1 second.
3.0 sec.
SYMBOLOGY SETTINGS TABLE
LR/ELR/2D Description Default
Codabar Disable
CLSI Editing When applied, the CLSI editing strips the start/stop
characters and inserts a space after the first, fifth, and
tenth characters of a 14-character Codabar barcode.
The 14-character barcode length does not include
start/stop characters.
No
NOTIS Editing Decide whether to
include the start/stop characters in the
data being transmitted.
NOTIS Editing is to strip the start/stop characters, i.e.
to disable "Transmit Start/Stop Characters".
No
Select Length
Any Length
One or two fixed lengths
Range (1~55)
Any Length
Code 128 Enable
GS1-128 Enable
Field Separator
Replacement
Decide whether to replace the field separator. If the
barcode contains Field Separator “0x1D”, it will be
changed to the desired Field Separator. For example, type
the desired character “;” (semicolon) as the new field
separator. Then if the barcode contains Field Separator
“0x1D”, it will be changed to “;”.
No
ISBT 128 Enable
Appendix III
LR/ELR LASER SCAN ENGINE
To Next Page
