1-6

Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router

OL-32185-02

Chapter 1 Overview of Cisco 4000 Series ISRs

Chassis Views

Figure 1-4 NIM and SM-X Slot with Divider

NIM slot 1 and 2 2 SM-X slot divider
